Develop intelligent noise reduction technology, make 008A Product
sound quality clear
008A product, as an important auxiliary equipment in tourism,
translation, training and other work, carries the receiver of the
audience regardless of the position before and after, within the
range of 0-200 meters from the lecturer, everyone can clearly hear
every word of the interpreter, free walking does not affect the
quality of reception.The 008A can be suitable for different
occasions, such as: factory or government reception VIP visit,
investigation, business negotiations to do wireless tour
explanation or simultaneous interpretation; School, company,
training institution, conference room, auditorium, classroom
lectures, lectures and other learning activities; Tour tour,
reception, company product promotion, museum, exhibition hall,
business exhibition guide and interpretation.
Product Specification:
| Name | Value |
| Working frequency: | 796-821MHz. Other frequecny can be customize |
| Channel quantity: | 158(high frequency 100+Low frequency 58),
Different frequency different channel quantities; |
| Receiving sensitivity: | -110dBm(typical); |
| Working voltage: | 3.0-5.0VDC,recycle polymer lithium battery; |
| Input: | Input(Transmitter):3.5mm microphone; |
| Output: | Output(receiver):3.5mm headphone |
| Oscillator: | PLL; |
| Second harmonic trap: | >40dbc; |
| Frequency response: | 20Hz-18KHz; |
| Signal to Noise Ratio: | 80dB(typical); |
| Image reject: | >80dB; |
| Mirror harmonic: | >75dB; |
| Separation factor: | 70dB(typical); |
| Frequency offset: | <3k; |
| Distortion factor: | <1%; |
| Oscillation frequency: | +/-2ppm; |
| Working current: | Transmitter:≤30~80mA;Receiver:≤50mA; |
| Working distance: | >=250m; |
| Working temperature: | -20℃—+70℃; |
| Dimensions: | 65*50*17mm; |
| Weight: | 50g(battery included); |
Product feature:
1. Many channels:dual channel 100 channels;
2. Far transmission distance:open field >= 250m;
3. The through wall effect is good:through concrete wall, brick
wall penetration effect;
4. The transmission effect to international level,the leading
domestic:Using core technology sound processing, perennial export
Europe and the United States and other countries!
Application:
Tour guide
When a guide leads tourists, it is natural to have situation
crowded and noisy among tourists.When this situation happens, it
isn’t comfortable for tourists to use the heavy and complicated
guide devices. Additionally, our product can be made for tourists
to concentrate on the tour and for a guide to make a tour
successfully.
Simultaneous interpretation
Have you ever experienced to use simultaneous interpretation
devices which are difficult and complicated? Our product is direct
and convenient product adapted in the international interpretation.
It is used in international conference, church, religious charities
and so on.
Reception of the inspection
In case of visiting tour like factories, docks and manufacturing
companies, there are a lot of inner noisiness. Therefore, it is
hard for a guide to lead the group there. If a guide uses our
product in this situation, he doesn’t have to divide the group and
can provide exact guidance even the big group. Also, our product
makes the image of a company to be enhanced and provides impressing
tour with using specific guide devices.
Recommended Accessories:
Microphone
Mono headphone
Charger (1 for 10)
Charging box
Packaging & Shipping:
Packing
Packaging Details: Standard export packing. One unit with one
independent box.
Shipping
DHL/FedEx/UPS/EMS: 3-7 workdays
Our Service:
Customized Logo
Free logo printing will be offered if order quantity is above 300pcs.
Our Warranty
2 Years warranty for all Transmitter & Receiver.
Spare Parts
A proportion of spare parts will be shipped along with formal
orders.
